CV-tech Clutch
Powered by Perkins
MODEL | UTV800 |
Size: L×W×H | 3018×1543×1995 mm |
Wheelbase | 1930 mm |
Ground clearance | 280 mm |
Dry weight | 745 kg |
Loading capacity | 300 kg |
Fuel Tank Capacity | 35 L |
Max speed | >40 km/h |
Specification of tire | Front: AT26X9-14 Rear: AT26X11-14 |
Brake system control model | Front: Foot brake Rear: Foot brake |
Brake system model | Front: Disk brake Rear: Disc brake |
Suspension type | Front:Twin-A arms independent suspension Rear: Twin-A arms independent suspension |
Engine type | Perkins |
Model | 4 Cycle、Inline,water-cooled Diesel |
Cylinder dimension | 762cc |
Bore and Stroke | 67×72 mm |
Rated power | 15.3/3600 (kw/r/min) |
Max torque | 44.5/2200 (Nm/r/min) |
Compression Ratio | 23.5:1 |
Fuel system | EFI |
Start type | Electric starting |
Transmission | Automatic L-H-N-R |
Loading quantity(40’HQ) | 11 |
