| MODEL | M550L |
| Size: L×W×H | 2330×1160×1265 mm |
| Wheelbase | 1455 mm |
| Ground clearance | 270 mm |
| Dry weight | 384 kg |
| Loading capacity | 129 kg |
| Fuel Tank Capacity | 14.5 L |
| Max speed | 80 km/h |
| Specification of tire | Front: AT25×8-12 Rear: AT25×10-12 |
| Brake system control model | Front: Hand brake,foot brake Rear: Hand brake,foot brake |
| Brake system model | Front: Disk brake Rear: Disk brake |
| Suspension type | Front: McPherson independent suspension Rear: Twin-A arms independent suspension |
| Engine type | LH188MR-A/LH188MR |
| Model | Single cylinder,4 stroke,SOHC,liquid cooled |
| Cylinder dimension | 493 cc |
| Bore and Stroke | 87.5×82 mm |
| Rated power | 24/6500 (kw/r/min) |
| Max torque | 38.8 Nm/5500 (Nm/r/min) |
| Compression Ratio | 10.2:1 |
| Fuel system | C.D.I/EFI |
| Start type | Electric starting |
| Transmission | Automatic L-H-N-R |
| Loading quantity(40’HQ) | 30 |
