MODEL M550L
Size: L×W×H 2330×1160×1265 mm
Wheelbase 1455 mm
Ground clearance 270 mm
Dry weight 384 kg
Loading capacity 129 kg
Fuel Tank Capacity 14.5 L
Max speed 80 km/h
Specification of tire Front: AT25×8-12
Rear: AT25×10-12
Brake system control model Front: Hand brake,foot brake
Rear: Hand brake,foot brake
Brake system model Front: Disk brake
Rear: Disk brake
Suspension type Front: McPherson independent suspension
Rear: Twin-A arms independent suspension
Engine type LH188MR-A/LH188MR
Model Single cylinder,4 stroke,SOHC,liquid cooled
Cylinder dimension 493 cc
Bore and Stroke 87.5×82 mm
Rated power 24/6500 (kw/r/min)
Max torque 38.8 Nm/5500 (Nm/r/min)
Compression Ratio 10.2:1
Fuel system C.D.I/EFI
Start type Electric starting
Transmission Automatic L-H-N-R
Loading quantity(40’HQ) 30
