DETAILS

MODEL T-BOSS 550
Size: L×W×H 2730×1460×1885 mm
Wheelbase 1855 mm
Ground clearance 280 mm
Dry weight 525 kg
Loading capacity 300 kg
Fuel Tank Capacity 26 L
Max speed >70 km/h
Specification of tire Front: AT25×8-12
Rear: AT25×10-12
Brake system control model Front: Foot brake
Rear: Foot brake
Brake system model Front: Disk brake
Rear: Disc brake
Suspension type Front:Twin-A arms independent suspension
Rear: Twin-A arms independent suspension
Engine type LH188MR-A
Model Single cylinder,4 strokes,water cooled,4 valve
Cylinder dimension  493cc
Bore and Stroke 87.5 x 82 mm
Rated power 24/6500 (kw/r/min)
Max torque 38.8/5500 (Nm/r/min)
Compression Ratio 10.2:1
Fuel system EFI
Start type Electric starting
Transmission Automatic L-H-N-R
Loading quantity(40’HQ) 16
